582

STEERING SYSTEM

9. Remove the pinion bearing retainer ring (circlip) (06)

10. Remove yoke cover (10)

5. Remove the Bellows (18) on either side

6. Release the lock washer

7. Loosen and take out the inner ball joint (13)

8. Take out oil seal (12) and pinion cover (11)
