THERMAL PROTECTOR DISASSEMBLY
- Remove the clamp thermal screw
- Remove the thermal protector (Wipe the silicon
grease on the compressor side completely later)
THERMAL PROTECTOR ASSEMBLY
- Silicon coating to be applied between compressor
and contact face to avoid gap when thermal
protector is mounted.
- Place the glass tube till it hits the Protector.
- Insert the Protector side lead wire into the Rear
Case harness housing keeping the glass tube as
shown in previous point.
