CENTRE CONSOLE
Removal
1. Pull the gear shifter cover out.
2. Remove two screws located at each side
(sideways) of centre console.
3. Remove the screw located at centre of cup holder
assembly.
4. Disconnect electrical connectors of power window
switch and power socket.
5. Take out center console alongwith power window
switch and power socket.
Installation
1. Connect the electrical connectors of power window
switch and power socket.
2. Fit all mounting screws of centre console assembly.
