DRIVETRAIN

5. Take out rollers (5) from tripod (4).

4. Remove the circlip (3) with circlip plier.

2. Take out tulip joint (1 or 11).

3. Remove the spring (2).

Removal

1. Remove boot clamp (large) (6) from the drive shaft

by tapping with blunt screw driver.

NOTE :

Tap at clamp ear junction.
