NANO ePAS

390

DRIVETRAIN

5. Invert the assembly and insert the circlip on the

groove using a circlip plier.

6. Insert the spacer.

B. ASSEMBLY

1. Insert the selector shaft bush using a suitable

drift.

2. Press the oil seal into place, using a suitable

drift.

4. Insert the selector shaft along with the dust cap

into the top cover.

3. Insert the dust cap on to the selector shaft from

below and align the projection between the two

gaps in the weld zone as shown.
