DRIVETRAIN
(c) Clutch Cable Replacement
Removal:
1. Loose & remove the clutch cable lock nut (1) &
take out the pin (2) to make the clutch cable free
from transaxle side.
2. Now take out the clutch cable from the clutch pedal
lever as cable is free from the transaxle side.
3. Pull the clip to release the clutch cable.
4. Loosen & take out all the clamps which are bolted
on the under side of the body & then release the
clutch cable from the firewall.
7. Place the clutch release lever on clutch release
yoke end (6).
8. Insert the bolt (7) into the clutch release lever hole
& insert the nut (8) and then tighten the bolt
