ENGINE COOLING COMPONENTS

13

6. Connect both inlet and outlet radiator hoses

clamps.

7. Install the condensor assembly carefully.

8. Tighten condenser bolts mounted on the both

side of the body as per the specified torque.

(8 Nm)

9. Tighten the clamp bolt for radiator and

condenser hoses as per the specified torque.

(9 Nm)

10. Connect high and low side refrigerant hose

and tighten their bolts as per the specified

torque. (8 Nm)

NOTE

Replace ‘O-rings’ of high and low side

refrigerant hoses if necessary to avoid leakage.

11. Tighten the drain plug.
