ENGINE 273 MPFI
SYSTEM MAINTENANCE
IGNITION COIL
(Refer EMS)
HT Cable
Removal of HT Cable:
•
Remove the HT Cable fromHT coil end.
CAUTION
Hold the HT cable nearer to the end as shown in
picture.
•
Remove theHTcable from the Spark plug by pulling
slightly.
CAUTION
Hold the HT cable nearer to the end as shown in
picture.
Inspection of HT Cable:
•
Check the HT Cable for any external damage ,
crack or torned bellow.
•
Check the resistance value of the HT cable in hot
& cold condition using multimeter ( nominal
values : 2.2 k-ohm to 5.02 k-ohm).
