STEERING
27
8.6 STEERING SYSTEM DTC CODES.
Sr.
No.
Displayed DTC
Code
DTC Description
1.
U3001 - 00
Control Module Improper Shutdown Performance
2.
U3006 - 16
Control Module Input Power “A” – Circuit Voltage below Threshold
3.
U3006 - 17
Control Module Input Power “A” – Circuit Voltage above Threshold
4.
U1006 - 42
Control Module Internal – General Memory Failure (RAM)
5.
U1006 – 4B
Control Module Internal – Over temperature
6.
U1006 – 04
Control Module Internal – System Internal Failure
7.
U1006 – 49
Control Module Internal –Internal Electronic Failure
8.
P0602 – 57
Control Module Programming Error – Invalid/Incompatible Software
Component
9.
P062F – 00
Internal Control Module EEPROM Error – no sub type information
10. C1304-01
Steering torque sensor – General electrical failure
11. C1305-01
Steering rotor position sensor-General electrical failure
12. C1305-02
Steering rotor position sensor-General signal failure
13. C130F-31
Steering torque index signal – No signal
14. C1312-62
Rotor position sensor signal “A” to “B” – Signal compare failure
15. C1315-54
Steering angle calibration – Missing calibration
16. C1315-64
Steering angle – Signal Plausibility failure
17. C1318-49
ASIC internal voltage faults-Internal electronic failure
18. C1319-01
Steering torque sensor current failure-General electrical failure
19. C131A-04
Control module reduced functionality-System internal failure
20. C131B-01
Drive motor control circuit failure- General electrical failures
21. C1314-01
Drive motor “A” phase current – General electrical failures
22. P0602 – 54
Control Module Programming Error –Missing Calibration
23. C1314-19
Drive motor “A” phase current - Circuit current above threshold
24. C131C-54
Motor calibration comparison Missing - Missing Calibration
25. C1314-13
Drive motor “A” phase current - Circuit open
26. C131D-01
Rotor position sensor stimulus-General electrical failure
27. U0028-13
Vehicle Communication Bus A-open circuit
