BRAKES
3
ABS SPECIFICATIONS
System Description
Specifications
General
System
ABS 9
Type
4 Channel ABS system with 4 wheel speed sensor
Control
Microprocessor based ECU
Hydraulic
Control Unit
(HCU)
Type
Diagonal (X) split
Hydraulic control
method
3 modes
-
Pressure Increase/Hold/ Decrease
Type of pump
Two piston pump
Type of motor
DC
Electronic
Control Unit
(ECU)
Operating voltage
12 V
Operating
temperature
- 40° C to + 120° C
ABS sensors
Type
Active hall effect
Resistance
High resistance > 3M
Air Gap
Front = 0.5 mm to 1.5 mm
Air Gap
Rear = 0.1 mm to 1.4 mm
Operating
temperature
- 40° C to + 115° C
