GENERAL
17
1.10. TECHNICAL SPECIFICATION FOR ZEST
1. ENGINE
Model
:
1). TATA 1.3L SDE (90PS)
2). TATA 1.2L REVOTRON TURBO (85PS)
Type
:
1). Four stroke, 4 cylinder, water cooled, direct injection
type, 1.3 QUADRAJET Turbo Intercooled diesel
engines.
2). Four stroke, Four Cylinder Water Cooled Multi point
Fuel Injection Engine.
No. Of Cylinder
:
Four Inline
Bore / Stroke
:
1). 69.6 mm x 82 mm
2). 75 mm x 67.5 mm
Capacity
:
1). 1248 cc
2). 1193
Max. Engine Output
:
1). 90 PS at 4000 rpm
2). 85 PS at 5000 rpm
Max. Torque
:
1). 200 Nm @ 1750-3000 rpm
2). 140 Nm @ 1500-3500 rpm
Compression Ratio
:
1). 17.6:1
2). 17.6:1
3). 9.0:1
Firing Order
:
1 - 3 - 4 – 2
Engine Oil Capacity
:
1). 3.2 Litre.
3). 4.0 Litre
2. CLUTCH
Type
:
Single plate dry friction diaphragm type.
Outside diameter
:
215mm (1.3L SDE (90PS))
of clutch lining
200mm (REVOTRON)
Friction area
:
386 sq.cm. (90PS)
346 sq. cm. (REVOTRON)
3. TRANSAXLE
Model
:
FIAT C-549 (5 Speed) with overdrive
Type
:
5-speed manual, Synchromesh on all forward gears
and sliding mesh for reverse gear
No. of gears
:
5 forward, 1 reverse.
Model
:
TA-65-5*(5 Speed) with overdrive
Type
:
5-speed manual, Synchromesh on all forward gear and
sliding mesh for reverse gear
No. of gears
:
5 forward, 1 reverse.
