Electrical
BOLT / ZEST
SR . NO
DESCR IP T ION
P AGE NO
01
INFO FITMENT DRG FOR WH BATTERY POSITIVE CABLE BOLT
QUADRAJET 75PS
87 - 89
02
INFO FITMENT DRG FOR WH BATTERY POSITIVE CABLE BOLT / ZEST
90PS QUADRAJET AMT
90 - 93
03
INFO FITMENT DRG FOR WH BATTERY POSITIVE CABLE BOLT / ZEST
REVOTRON
94 - 97
04
INFO FITMENT DRG FOR WH BATTERY NEGATIVE EARTH CABLE
BOLT / ZEST QUADRAJET / REVOTRON
98 - 102
05
INFO FITMENT DRG FOR W/H SHORTLINK ALTERNATOR BOLT ZEST
QUADRAJET ALL
103 - 105
06
INFO FITMENT DRG FOR W/H SHORTLINK ALTERNATOR BOLT /
ZEST REVOTRON
106 - 108
07 INFO FITMENT DRAWING FOR REAR DOOR LH AND RH
109 - 114
08 INFO FITMENT DRG FOR CCB EARTH CABLE BOLT AND ZEST ALL
115 - 118
09 INFO FITMENT DRAWING FOR GARNISH PIGTAIL
119 - 122
10 INFO FITMENT DRG FOR HT CABLES 1.2 REVOTRON
123 - 126
11
WORK INSTRUCTION FOR ANTO-ROTATION EARTH TERM INAL
HANDLING
127
12
WORK INSTRUCTION FOR UPSTREAM LAMBDA CONNECTOR
HANDLING
127
13
INSTRUCTION FOR CONNECTOR MOUNTING & LOCKING
PROCEDURE - LH SIDE FRAME
128
14
INSTRUCTION FOR CONNECTOR MOUNTING & LOCKING
PROCEDURE - RH SIDE FRAME
128
SR . NO
DESCR IP T ION
P AGE NO
15 INFO FITMENT DRAWING FOR W/H FLOOR RH ZEST
129 - 143
16 INFO FITMENT DRAWING FOR BUMPER WH
144 - 148
17 INFO FITMENT DRAWING FOR ZEST FLOOR LH
149 - 157
18
ANTENNA CABLE ROOF SIDE ZEST ALL & M ICROPHONE CABLE
ZEST XM XT
158 - 162
19 INFO FITMENT DRAWING FOR FRONT WH QUADRAJET AMT
163 - 185
20 INFO FITMENT DRAWING FOR 1.2 REVOTRON EMS WH
186 - 200
21 INFO FITMENT DRAWING FOR W/H FLOOR RH BOLT
201- 211
22 INFO FITMENT DRAWING FOR W/H FLOOR LH BOLT
212 - 221
23
INFO FITMENT DRAWING FOR ROOF WH BOLT ZEST
QUADRAJET & REVOTRON
222 - 225
24
INFO FITMENT DRAWING FOR W/H ANTENNA BOLT ALL &
M ICROPHONE CABLES BOLT XM XT ROOF
226 - 231
25 INFO FITMENT DRAWING FOR FRONT W/H QUADRAJET
232-269
26 INFO FITMENT DRAWING FOR FRONT W/H REVOTRON
270-306
27 INFO FITMENT DRAWING FOR COCKPIT W/H
307-346
28 INFO FITMENT DRAWING FOR ANTENNA CABLE COCKPIT SIDE
347-351
29 INFO FITMENT DRAWING FOR USB CABLE
352-353
30 INFO FITMENT DRAWING FOR TAILGATE
354-364
31 INFO FITMENT DRAWING FOR DRIVER AND CO-DRIVER DOOR PIGTAIL 365-373
32 INFO FITMENT DRAWING FOR DRIVER DOOR
374-385
33 INFO FITMENT DRAWING FOR CO- DRIVER DOOR
386-398
INDEX
